Reed Mat Jacquard 3K Carbon Fiber Fabric Engineering-Grade Weave

Get a Price/Quote

Reed Mat Jacquard 3K Carbon Fiber Fabric Engineering-Grade Weave Specification

Crimp Recovery
Excellent

Elasticity
High Modulus (230-240 GPa)

Crimp Frequency
Low (depends on jacquard configuration, typically <3/cm)

Elongation
1.4%

Staple Length
Not Applicable (Continuous Fiber)

Material
3K Carbon Fiber (Engineering Grade)

Fiber Length
Continuous Filament

Fineness (%)
99%

Pattern
Reed Mat Jacquard Weave

Use
Composite Reinforcement, Aerospace, Automotive, Sports Equipment

Feature
High Strength, Lightweight, High Modulus, Corrosion Resistant

Tensile Strength
3500 MPa

Moisture Absorption
Negligible

Surface Finish
Unidirectional/Matte

Width
1000 mm (standard), customizable available

Electrical Conductivity
Excellent

Thickness
0.26 mm nominal

Color
Black (Natural Carbon)

Operating Temperature
-40C to 200C

Weight
200g/m2 (10g)

Yarn Type
3K (3000 filaments per tow)

Resin Compatibility
Epoxy, Polyester, Vinyl Ester

Reed Mat Jacquard 3K Carbon Fiber Fabric Engineering-Grade Weave Trade Information

Minimum Order Quantity
100 Meter

Supply Ability
5000 Per Month

Delivery Time
10 Days

About Reed Mat Jacquard 3K Carbon Fiber Fabric Engineering-Grade Weave

Experience the unbeatable price and competitive pricing of Reed Mat Jacquard 3K Carbon Fiber Fabric, now offered in a clearance sale. Crafted with redoubtable engineering precision, this wondrous and first-rate carbon fiber fabric features a 3K tow weave delivering exceptional tensile strength (3500 MPa) and high-modulus elasticity (230-240 GPa). Its jacquard weave provides low crimp, excellent recovery, and superior compatibility with various resins. Perfect for aerospace, automotive, and sports equipment, it ensures lightweight, high strength, and corrosion resistance. Available in 1000 mm standard width and customizable options from a leading Indian manufacturer, exporter, and supplier.

Diverse Applications of Reed Mat Jacquard 3K Carbon Fiber Fabric

Reed Mat Jacquard 3K Carbon Fiber Fabric excels in demanding application media due to its high-strength, lightweight, and corrosion-resistant properties. Common areas of application include aerospace structures, automotive panels, and high-performance sports equipment, where durability and stiffness are paramount. As a composite reinforcement solution, it ensures reliability in both structural and non-structural uses, making it the preferred material for industries seeking advancements in material science and engineering-grade reinforcement for critical components.

Sample Availability, Certifications, and Global Export Markets

Stock ready samples of Reed Mat Jacquard 3K Carbon Fiber Fabric are available for immediate evaluation, ensuring quick decision-making and minimal expenditure. Each batch is delivered with the requisite certifications, attesting to its quality and compliance for engineering applications. With a strong presence in major export markets, this fabric is dispatched efficiently from India, serving global demands for advanced composites. Connect with our team to request samples and streamline your procurement process.

FAQ's of Reed Mat Jacquard 3K Carbon Fiber Fabric a Engineering-Grade Weave:

Q: How can the Reed Mat Jacquard 3K Carbon Fiber Fabric be customized to suit specific project requirements?

A: The width of the fabric can be tailored, and customers can select between unidirectional and matte surface finishes, ensuring compatibility with unique application needs and design specifications.

Q: What certifications accompany the Reed Mat Jacquard 3K Carbon Fiber Fabric when delivered to clients?

A: Each batch is provided with quality certifications, verifying compliance with engineering-grade standards and industry requirements, ensuring reliability for critical applications.

Q: When is it ideal to use this carbon fiber fabric in manufacturing processes?

A: This fabric is perfect when high tensile strength, lightweight construction, and corrosion resistance are needed, such as in aerospace, automotive, or sports equipment manufacturing.

Q: Where is the Reed Mat Jacquard 3K Carbon Fiber Fabric most commonly exported?

A: As a leading exporter and supplier from India, this fabric is dispatched to major international markets across North America, Europe, and Asia for advanced material applications.

Q: How does the fabric's electrical conductivity benefit modern engineering designs?

A: Its excellent electrical conductivity supports innovative composite designs that require both structural reinforcement and efficient electrical performance in advanced engineering applications.
