Name: 1K Carbon Fiber Fabric 5HS Weave
Brand: MARSHALL PACKINGS & INSULATIONS INDUSTRIES

Get a Price/Quote

MOQ : 100 Meters

1K Carbon Fiber Fabric 5HS Weave Specification

Width
100 cm (39 inches) standard, customizable

Stretch Type
Low stretch, inelastic

Pattern Type
5HS woven

Fabric Material
100% Carbon Fiber

Application
Reinforcement, lamination, structural applications

Weave Style
5HS (5 Harness Satin)

Water Proof
Yes

Material
Carbon Fiber

Texture
Smooth, glossy surface

Style
Satin weave

Yarn Count
1K (1000 filaments per tow)

Density
1.76 Gram per cubic centimeter(g/cm3)

Weight
130-150 gsm (grams per square meter)

Length
100 meters (customizable)

Strength
High tensile strength, up to 3400 MPa

Use
Composites, aerospace, marine, automotive, sports equipment

Attributes
High strength, lightweight, flexible, corrosion-resistant

Color
Black

Fabric Type
Woven carbon fiber fabric

Pattern
5 Harness Satin (5HS) Weave

Size
1K

Thermal Stability
Up to 400C without losing properties

Surface Treatment
No sizing or epoxy compatible

Filament Diameter
7 micron

Production Method
Woven on shuttleless looms

Resin Compatibility
Epoxy, polyester, vinyl ester

Packing
Rolls wrapped with protective film and carton packaging

Elongation at Break
1.8%

Roll Size
100 m/roll or as requested

Electrical Conductivity
Good conductive properties

1K Carbon Fiber Fabric 5HS Weave Trade Information

Minimum Order Quantity
100 Meters

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Meters Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 1K Carbon Fiber Fabric 5HS Weave

Jump on this New Release: our 1K Carbon Fiber Fabric 5HS Weave-engineered for redoubtable strength, terrific flexibility, and optimum endurance. With a 7-micron filament diameter and thermal stability up to 400C, this top-grade fabric boasts high tensile strength (up to 3400 MPa) and terrific corrosion resistance. Its smooth, glossy surface, in a sleek satin weave pattern, is lightweight yet powerful. Compatible with epoxy, polyester, and vinyl ester resins, it's a last-chance essential for aerospace, marine, automotive, and sports equipment applications. Rolls are expertly packaged and customizable to your requirements.

Versatile Applications & User-Friendly Process

1K Carbon Fiber Fabric 5HS Weave is widely used for reinforcement, lamination, and structural projects across composites, aerospace, marine, and automotive sectors. It's ideally applied using hand layup, vacuum bagging, or infusion methods. Suitable for professionals and hobbyists alike, this fabric delivers dependable results wherever durability and lightweight performance are a must, making it an optimum choice for high-performance equipment and demanding structural applications.

Export Advantages, Policies, and Domestic Market Reach

Our carbon fiber fabric is delivered efficiently to major export markets across North America, Europe, Asia, and the Middle East with secure packaging and streamlined transportation for reduced expenditure. Sample policies are flexible, supporting custom requests to match your requirements. Within India, our distribution network ensures timely deliveries to all major domestic markets, reinforcing our reputation as a trusted exporter, manufacturer, and supplier in the industry.

FAQ's of 1K Carbon Fiber Fabric 5HS Weave:

Q: How is the 1K Carbon Fiber Fabric 5HS Weave typically applied in structural projects?

A: This fabric is commonly applied using techniques such as hand layup, vacuum bagging, and infusion, allowing precise adaptation to reinforcement, lamination, or repair tasks in composite constructions.

Q: What are the primary benefits of choosing this carbon fiber fabric for composite applications?

A: The fabric offers terrific high tensile strength, exceptional thermal stability up to 400C, lightweight flexibility, good electrical conductivity, and corrosion resistance-ideal for high-performance and demanding environments.

Q: Where can the 1K 5HS Weave Carbon Fiber Fabric be used?

A: It's widely suitable for aerospace, marine, automotive, and sports equipment sectors, excelling in reinforcement, lamination, shell construction, and structural repairs requiring strong, lightweight materials.

Q: What is the compatibility of this fabric with different resins?

A: The fabric is engineered for optimum compatibility with epoxy, polyester, and vinyl ester resins, enabling versatile use in a wide range of composite manufacturing processes.

Q: How is your carbon fiber fabric delivered and packed for export?

A: Each roll is wrapped in protective film and packaged in sturdy cartons to ensure safe transportation. We offer efficient delivery to export and domestic markets, keeping your overall expenditure in check.
