1K Carbon Fiber Fabric 8HS Weave

Name: 1K Carbon Fiber Fabric 8HS Weave
Brand: MARSHALL PACKINGS & INSULATIONS INDUSTRIES

Get a Price/Quote

MOQ : 100 Meters

1K Carbon Fiber Fabric 8HS Weave Specification

Pattern Type
Woven

Fabric Material
Carbon Fiber

Weave Style
8HS (Eight Harness Satin)

Water Proof
Yes

Application
Aerospace, automotive, sports equipment, marine, industrial

Width
1000 mm (standard), customizable

Stretch Type
Non-stretch

Material
1K Carbon Fiber

Texture
Smooth, fabric-like

Style
Woven fabric

Yarn Count
1K (1000 filaments per tow)

Density
1.76 Gram per cubic centimeter(g/cm3)

Weight
90-110 gsm (grams per square meter)

Length
Roll form (customized length available)

Strength
High tensile strength (>3.5 GPa)

Use
Composite reinforcement, lamination, lightweight structures

Attributes
High strength, lightweight, durable, flexible

Pattern
8HS Weave (Eight Harness Satin)

Fabric Type
Carbon Fiber Fabric

Color
Black

Size
Standard/custom sizes

Surface Treatment
Sizing for epoxy compatibility

Resin Compatibility
Epoxy, polyester, vinyl ester resins

Filament Diameter
7 m

Thermal Conductivity
High

Areal Weight Tolerance
5%

Shrinkage
Minimal

Fire Retardant
Yes (inherent to carbon fiber)

Impact Resistance
Excellent

Operating Temperature Range
-40C to 200C

1K Carbon Fiber Fabric 8HS Weave Trade Information

Minimum Order Quantity
100 Meters

Payment Terms
Cash in Advance (CID)

Supply Ability
5000 Meters Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 1K Carbon Fiber Fabric 8HS Weave

Procure our superlative 1K Carbon Fiber Fabric with 8HS Weave, crafted for pristine performance and unrivaled durability. Featuring lustrous black strands of 1000 filaments per tow, this woven marvel boasts high tensile strength (>3.5 GPa), minimal shrinkage, and inherent fire-retardant properties. Our fabric's 8HS pattern delivers superior impact resistance and flexibility, while sizing ensures flawless epoxy compatibility. Compatible with epoxy, polyester, and vinyl ester resins, it is the ultimate bargain for aerospace, automotive, marine, and industrial applications. Custom lengths, widths, and sizes are offered for precise project needs.

Why Choose 1K Carbon Fiber Fabric 8HS Weave?

Experience the competitive advantage of our 1K Carbon Fiber Fabric with Eight Harness Satin Weave, designed for top-tier strength, flexibility, and minimal weight. Its superlative impact resistance and high thermal conductivity make it ideal for aerospace, automotive, sports equipment, marine, and industrial environments. This fabric is prized for composite reinforcement and lamination, excelling in lightweight structures such as panels, frames, and performance parts. Select it for projects demanding superior resilience and pristine finish.

Sample Availability, Packaging & Export Logistics

We offer pristine 1K Carbon Fiber Fabric 8HS Weave samples to facilitate evaluation and project compatibility. Each roll is shipped in secure, moisture-proof packaging for optimal protection during logistics. Our efficient export processes cater to global markets, with major shipments destined for North America, Europe, Asia, and the Middle East. As a premier exporter and supplier from India, we ensure our clients always benefit from competitive pricing, timely delivery, and exceptional customer support.

FAQ's of 1K Carbon Fiber Fabric 8HS Weave:

Q: How is the 1K Carbon Fiber Fabric 8HS Weave typically used?

A: This carbon fiber fabric is widely used in composite reinforcement, lamination, and construction of lightweight structures for aerospace, automotive, marine, sports equipment, and industrial applications.

Q: What makes the 8HS Weave pattern advantageous?

A: The Eight Harness Satin (8HS) Weave offers excellent drapability, flexibility, and a lustrous appearance, making it suitable for complex moldings and aesthetically demanding projects.

Q: When should I choose this fabric for my project?

A: Choose this fabric when your project requires high tensile strength, minimal shrinkage, fire retardancy, and compatibility with various resins such as epoxy, polyester, and vinyl ester.

Q: Where are your main export markets for this product?

A: We mainly export to North America, Europe, Asia, and the Middle East, catering to aerospace, automotive, and industrial sectors.

Q: What is the process for procuring customized sizes or sample rolls?

A: Simply contact our sales team with your required dimensions or request for samples, and we will offer customized solutions tailored to your project needs.

Q: How does sizing treatment enhance epoxy compatibility?

A: The surface sizing treatment improves bond strength and ensures uniform resin wet-out, resulting in enhanced performance and longevity in composite applications.
